Fire Retardant Panels BS1D0
This plywood is specially treated to achieve fire classification BS1D0. The surfaces can be lacquered, oiled, painted, brushed to produce the design according to customer’s needs.
Option 1: treated core birch plywood, veneer/stain of your choice
Option 2: core cement-bounded particle board, veneer of your choice
Perforated Fire retardant Panels can also be used as Acoustic panels
Euroclass Classification
| Class |
Material Description |
Performance description |
Flashover |
| A1 |
Non flammable |
No contribution to fire |
Over 20 minutes to flashover |
| A2 |
Non flammable |
No contribution to fire |
Over 20 minutes to flashover |
| B |
Flammable |
Very limited contribution to fire |
Over 20 minutes to flashover |
| C |
Flammable |
Limited contribution to fire |
Between 10 and 20 minutes to flash over |
| D |
Flammable |
Acceptable Contribution to fire |
Between 10 and 20 minutes to flash over |
| E |
Flammable |
Acceptable Contribution to fire |
Less than 2 minutes to flashover |
| F |
Flammable |
No performance requirements |
Less than 2 minutes to flashover |
Flaming Droplets Classification
| D0 |
No flaming droplets |
| D1 |
No flaming droplets that persist for less than 10 seconds |
| D2 |
Flaming droplets |
Smoke Classification
| S1 |
Low Smoke |
| S2 |
Medium Smoke |
| S3 |
High Smoke |
Treated Plywood V.S. Normal Plywood Treated Perforated Plywood V.S. Normal Perforated Plywood
For more information about surface treatment, please check coloring and veneering page.
Panels produced by Technomar & Adrem can be used as Wall or Ceiling Panels depending on the fixing profile used. For more information please visit installation guide.
